Thread Ball Winding Machine
Technical Parameters
| Model |
SA-O06/N(U) |
SA-O10/N(U) |
SA-O12/N(U) |
|
Spindle No |
6 spindles |
10 spindles | 12 spindles |
|
Ball Weigh |
10-200g | ||
|
Motor Power |
750w |
||
|
Rotation Rate |
1450 r/min |
||
| Machine Size |
2.3*0.7*1.1M |
2.8*0.7*1.1M |
3.3*0.7*1.1M |
| Machine Weight |
390KW |
420KG |
450KG |
| Voltage |
380V, 220V or customized |
||
|
Applicable Materials |
Plastic, Fiber, Wool, Cotton, Paper, Jute, Sisal hemp, Chenille, Manila, Acrylic, etc. |
||
Customization
The machine is customizable with spindle numbers. 10 & 12 spindles are most popular, 4 spindles, 6 spindles, 20 spindles or other customized spindle quantity are also available.
Function
The thread ball making machine is suitable for different materials such as Plastic, Fiber, Wool, Cotton, Paper Jute Chenille, Manila, Acrylic, etc. The winder can make the filament into both ball shape and cross shape.
Installation and Operation
This rope ball winder is easy to operate. Our company provides a full set of installation and operation videos and instruction manuals to help customers standardize their use behavior. It is very easy to learn. Customers are welcomed to provide sample to test to find the most suitable machine to make proper products, saving time, saving costs, thereby increasing profit margins.
More Choices
There are two types of ball winding machines are available. For the independent controlling system type, we can do single spindle, double spindles, four spindles, five spindles or more. For the shared controlling system type, we normally do 10 or 12 spindles. We can also provide customized machinery according to your needs.
